TECHNICAL SPECIFICATIONS
FRAMEFACT 9m carbon front triangle, 29" geometry, FACT IS construction, gussetless TT S/M, M5 aluminum chainstays & seatstays, tapered HT, carbon PF-30 BB, 142mm drop-outs, sealed cartridge bearing pivots, replaceable derailleur hanger, 100mm travel
REAR SHOCKFox/Specialized remote Mini-Brain, inertia valve, w/ Brain Fade adjust, 187x47mm, 29er hose length
FORKRockShox Reba RLT 29, tapered alloy steerer, compression and rebound adj. LO w/external floodgate adj., standard drop-outs, 100mm travel
HEADSET1-1/8" and 1-1/2" Threadless, Campy style upper with 1.5" lower, cartridge bearings
STEMSpecialized XC, 3D forged alloy, 4-bolt, 31.8mm clamp, adjustable rise
HANDLEBARSSpecialized XC flat, 2014 butted alloy, 680mm wide, 8 degree backsweep, 31.8mm
GRIPSSpecialized lock-on, S/M: Grappler, Other: Rocca
FRONT BRAKECustom
Avid Elixir R SL, hydraulic disc, tool-less reach adjust, alloy backed semi-metallic pads, stainless hardware, G3 Clean Sweep rotor, S/M: 160mm, L/XL: 185mm rotor
REAR BRAKECustom
Avid Elixir R SL, hydraulic disc, tool-less reach adjust, alloy backed semi-metallic pads, stainless hardware, G3 Clean Sweep rotor, 160mm rotor
BRAKE LEVERSCustom
Avid Elixir R SL hydraulic, tool-less reach adj.
FRONT DERAILLEURSRAM X.7, 10-speed, S3 direct mount for DMD, bottom pull
REAR DERAILLEURSRAM X.9, 10-speed, mid cage
SHIFT LEVERSSRAM X.7, 10-speed, aluminum trigger
CASSETTE
Shimano HG81, 10-speed, 11-36t
CHAINKMC X10, 10-speed, w/ reuseable Missing Link, nickel plates
CRANKSETCustom
SRAM S-1250, 7050 alloy arms, 10-speed XC double for 29er, GXP spindle, S: 170mm, others: 175mm
CHAINRINGS38A x 24A, 4-bolt, 104/64mm
BOTTOM BRACKET
SRAM GXP, outboard bearing
PEDALSResin Test Ride Pedals with toe clips, CEN std.
RIMSCustom
DT Swiss X450SL, alloy 29", 24mm w/ eyelets, 32h
FRONT HUBSpecialized Hi Lo disc, laser-etched logo, OS 28 end caps, sealed cartridge bearing, RWS, 32h
REAR HUBSpecialized Hi Lo 142+ disc, laser-etched logo, double sealed cartridge bearing, QR, 32h
SPOKESDT Swiss Champion 1.8mm (15g) stainless
FRONT TIRES-Works "The Captain", 120 TPI, 2Bliss ready aramid bead, dual compound, 29x2.0"
REAR TIRES-Works Renegade, 120 TPI, 2Bliss ready aramid bead, dual compound, 29x1.95"
INNER TUBESUltralight presta valve
SADDLESpecialized BG Phenom Comp, hollow Cr-Mo rails, 143mm width
SEATPOST2014 butted alloy, single bolt setback, 30.9mm, 400mm
SEAT BINDER36.9mm clamp ID, 7050 hard annodized alloy collar w/ QR, for carbon frame
NOTESProtective clear coat, derailleur hanger, reflectors, owners manual
